• Metallized polypropylene film design,excellent self-healing property


• Anti-explosion design,more safety overpressure protection

• The capacitors particularly suit for AC filter circuit in power electric equipment and UPS power unit.They have ability to withstand high harmonic current, peak current and peak voltage

• For tab type, the capacitors meet 96H neutral salt spray

Reference Standards

• IEC61071

• IEC60831

• RoHS

• UL 810

• Features

• Low ESR,high ripple current handling capabilities

• Low ESL, less than 8nH

• Self-healing property

3 / 13

• Plastic case,filled with resin

• Applications

• High frequency inverter

• Reference Standards

• IEC61071

• IEC60068

• RoHS

• UL 810







• Used in DC-link circuits,can replace electrolytic capacitors


• Low ESR,high ripple current handling capabilities

• Low ESL

• Self-healing property

• Long life time

• Aluminum case,filled with resin

Applications

• Used in inverters of wind power and solar power

• Transportation: EV or HEV

• Welders, Elevators, Motor driver systems

Reference Standards

• IEC61071

• IEC60068

• RoHS

• UL 810

Power Electronic CapacitorsMKP AC Filter – Box

• Metallized polypropylene film design,excellent self-healing property


• Excellent electric property

• Plastics case(UL94 V-0), filled with resin

• Suitable for small power AC output filter, i.e. UPS, Solar photovoltaic DC/AC inverter with LCL filter

• The capacitors are designed for mounting on printed-circuit boards (PCB)

• Reference Standards

• IEC61071

• IEC60831

• RoHS

• UL 810

• Widely used in high voltage,high frequency circuit


• Widely used in high voltage,high frequency circuit


• Low loss and small inherent temperature rise

• Excellent active and passive flame resistant abilities

• Especially designed as snubber capacitor for IGBT

• Plastics case,filled with resin

Reference Standards

• IEC61071

• IEC60068

• RoHS

• UL 810
